Operating at the absolute maximum TJ of 150☌ can affect reliability. The maximum allowable power dissipation at any allowable ambient NOTE 1: Maximum power dissipation is a function of TJ(max), θJA, and TA. Exposure to absolute-maximum-rated conditions for extended periods may affect device reliability. These are stress ratings only, andįunctional operation of the device at these or any other conditions beyond those indicated under “recommended operating conditions” is not † Stresses beyond those listed under “absolute maximum ratings” may cause permanent damage to the device. Storage temperature range, Tstg –65☌ to 150☌. Lead temperature 1,6 mm (1/16 inch) from case for 10 seconds 260☌. Operating virtual junction temperature, TJ 150☌. Input voltage, VI: ♚7824C 40 V.Īll others 35 V. Production processing does not necessarily includeĪbsolute maximum ratings over virtual junction temperature range (unless otherwise noted)† Products conform to specifications per the terms of Texas Instruments Texas Instruments semiconductor products and disclaimers thereto appears at the end of this data sheet.Ĭopyright  2003, Texas Instruments IncorporatedPRODUCTION DATA information is current as of publication date. Please be aware that an important notice concerning availability, standard warranty, and use in critical applications of † Package drawings, standard packing quantities, thermal data, symbolization, and PCB design guidelines are available at TO-220, short shoulder (KCS) Tube of 20 ♚7815CKCS TO-220, short shoulder (KCS) Tube of 20 ♚7812CKCS TO-220, short shoulder (KCS) Tube of 20 ♚7808CKCS TO-220, short shoulder (KCS) Tube of 20 ♚7805CKCS In addition to use as fixed-voltage regulators, these devices can be used with external components to obtainĪdjustable output voltages and currents, and also can be used as the power-pass element in precision The internalĬurrent-limiting and thermal-shutdown features of these regulators essentially make them immune to overload.

Each of these regulators can deliver up to 1.5 A of output current. These applications include on-card regulation for elimination of noise and distribution problems associated with This series of fixed-voltage integrated-circuit voltage regulators is designed for a wide range of applications. D Internal Short-Circuit Current Limitingĭ Output Transistor Safe-Area Compensation
